Product Name:
W2.5X1220 W2.0X2040A W2.5X2040A W2.0X2540A W2.5X2540AW2.0X3050A W1.2X3700A W0.8X4000A
No. :
 |
2. With segment bending blade for the bending of box section
3. Various widths segment shiftable setup
4. With balanced hammer, it can easy to operate and easy for folding
5. Its maximum bending thickness is 2.5mm.
Specifications
1. With segment bending blade for the bending of box section.
2. Various widths segment shiftable setup.
3. With balanced hammer, it can easy to operate and easy for folding
|
Model |
Capacity(mm) |
Packing size(cm) |
N.W./G.W.(kg) |
||
|
Length |
Thickness |
Angle |
|||
|
W2.5X1220 |
1220mm(48") |
2.5mm(12Ga) |
0-135° |
171x75x94 |
513/575 |
|
W2.0X2040A |
2040mm(80") |
2.0mm(14Ga) |
0-135° |
255x76x100 |
850/1000 |
|
W2.5X2040A |
2040mm(80") |
2.5mm(12Ga) |
0-135° |
255x76x100 |
1145/1295 |
|
W2.0X2540A |
2540mm(100") |
2.0mm(14Ga) |
0-135° |
300x76x100 |
1190/1360 |
|
W2.5X2540A |
2540mm(100") |
2.5mm(12Ga) |
0-135° |
300x76x100 |
1310/1480 |
|
W2.0X3050A |
3050mm(120") |
2.0mm(14Ga) |
0-135° |
350x76x110 |
1490/1690 |
|
W1.2X3700A |
3700mm(146") |
1.2mm(20Ga) |
0-135° |
425x85x120 |
2450/2670 |
|
W0.8X4000A |
4000mm(157") |
0.8mm(22Ga) |
0-135° |
470x90x120 |
2700/2950 |
