Product Name:
CK6140
No. :
 |
high rigidity pedestal and wider lay board are suitable for heavy cutting
four station electric turret
inverter stepless speed
|
Model |
CK6136B |
CK6136 |
CK6140 |
|
Max.swing over bed |
360mm |
360mm |
400mm |
|
Max.swing over cross slide |
180mm |
180mm |
250mm |
|
Max.turning length |
WithChuck700mm/ Withcollet750mm |
Chuck490mm/ collet580mm |
Chuck600mm/ collet700mm |
|
Spindle bore |
48mm |
48mm |
48/83mm |
|
Max.diamete rof the bar |
41mm |
41mm |
41/65mm |
|
Spindle speed |
150-2000 |
150-2000 |
150-1800 |
|
Spindle nose |
A2-6 |
A2-6 |
A2-6/A2-8 |
|
Spindle motor power |
5.5kw |
5.5kw |
5.5/7.5kw |
|
X/Z axis position accuracy |
0.01/0.015mm |
0.01/0.015mm |
0.01/0.015mm |
|
X/Z axis repeatability |
0.012/0.013mm |
0.012/0.013mm |
0.012/0.013mm |
|
X/Z axis motor torque |
4/6N.m |
4/6N.m |
4/6N.m |
|
X/Z axis motor power |
1/1.5kw |
1/1.5kw |
1/1.5kw |
|
X/Z axis rapid speed m/min |
8/10 |
8/10 |
8/10 |
|
Tool post type |
4/6tool electric turret |
4/6tool electric turret |
4/6tool electric turret |
|
Tool bar section |
20*20mm |
20*20mm |
20*20mm |
|
Tailstock sleeve dia. |
60mm |
60mm |
60mm |
|
Tailstock sleeve travel |
100mm |
100mm |
100mm |
|
Tailstock taper |
MT4 |
MT4 |
MT4 |
|
N.W. |
1700kg |
1560kg |
1800kg |
|
Machine dimension(L*W*H) |
1860*1060*1600mm |
2000*1200*1620mm |
2200*1100*1620mm |
